Most electronic circuits now-a-days include a lot of SMD components. That said, through hole (TH) components are still widely used. Soldering TH components onto PCBs requires holding them in place in the right position and orientation. This is a skill by itself. Done wrong, this can result both in ugly looking products (e.g. angled connectors), even leading to product rejections. This is something that every every hobbyist, electronics enthusiast, and even professional ends up dealing with at one time or the other.
One way of dealing with this is to build a jig specific to the PCB to hold the electronics components in place. Using such a jig simplifies the soldering process. The user only needs to make the soldering joint, without worrying about keeping the component in place. Such a jig can be 3D printed, making it widely accessible. However, designing and tuning such jigs requires CAD design expertise. It can take many painstaking trials and prints to get this right. Such skills don't transfer easily across engineers.
JigIta is a software tool that generates a 3D printable jig from any PCB design in minutes in one single step. With the jig in hand, soldering becomes as easy as 1-2-3
Insert components into the jig
Slide in PCB into place
Solder away for perfect results
(Here's an example of the workflow for a Raspberry Pi Pico)
JigIt is parametric. It allows complete control over fitting tolerances, while offers a range of component fitting structures tailored to real world usage. JigIt cuts hours of work into minutes. JigIt can also create designs that need less material for 3D printing, compared to hand made designs. All these make JigIt suitable for individuals, instructors as well as in industrial applications.
This talk will illustrate how you can use JigIt to simplify your own soldering workflows. We'll step through concepts, build a jig to solder headers onto a Rasperry Pi Pico, and then move look advanced examples using various open source boards (many examples are shown on the main project page also).
One of hidden gems in JigIt is a novel technique, called "corner avoidance", that leads to 3D models which can tightly fit small components. This technique is generically applicable to various designs, and will be covered in this talk.
Learn how to generate 3D printable jigs to solder your own boards
Get familiar with the "corner avoidance" technique to generate better fitting 3D printable models
